High-altitude radar detection
Accurately detect subtle movements
Creatrol's high-altitude radar motion detection sensor uses a high-altitude radar chip to transmit and receive microwave high-frequency signals. After algorithm processing, it can sensitively sense the subtle movements and motion of the human body even at an altitude of 4 to 12 meters. It has a built-in 0-32000Lux digital illuminance counting chip that can simultaneously detect ambient light.
??? ? Suitable for wide open spaces High speed The radar is suitable for installation at high altitudes (4-8m) and has a large detection range, making it more suitable for various scenarios requiring large-area movement or small-scale movement detection. |    |
??? ? Built-in digital illuminance measurement chip The product has a built-in 0-32000Lux digital illuminance measurement chip that can simultaneously detect ambient light. This means that the sensor can not only detect subtle movements of the human body, but also monitor the light intensity of the surrounding environment, providing data support for intelligent lighting control. | |
??? ? Ultra-small size The sensor adopts a 35mm ultra-small opening and a 25mm ultra-thin body design. It is smaller than 99% of sensors on the market and is easy to install and hide. | |
??? ?Multiple installation methods Supports a variety of mounting accessories to adapt the sensor to different installation environments and requirements, including embedded installation, wall mounting, ceiling extension installation, adjustable angle installation, surface mounting and other installation methods. | |
??? Rich application scenarios It is suitable for public places with high open spaces such as airports, railway stations, factories, and schools, and can achieve precise energy-saving control, with lights turning on when there are people or slight movements, and turning off when there are no people. | |
| Designation | Value |
| Detection Mode | 5.8GHz High - Ceilinged Space Radar |
| Install Height | 2.0 ~ 12.0 meters |
| Detection Angle | 360° |
| Detection Range | When the installation height is 8 meters Micro motion/motion detection diameter ≤ φ15.0 meters |
| Detection Sensitivity | 0~100% |
| Illuminance Sensing | 0 ~ 32000 Lux (Accuracy ± 4%） |
| Product Dimensions | φ43mm*35mm*25mm |
| Hole Size | φ35mm，depth ≥ 100mm |
| Product Weight | 18g |
| Auxiliary Power Supply | 12~30V DC |
| Working Environment | Temperature -20 ~ 45 ℃ Humidity < 95% |
| Delay Time | 1 ~ 3600 seconds |
| KNX Input | KNX12~30V(6mA) |
| AUX Input | DC12~30V(0.5W) |
| LED Indicator | Displays the working status of the sensor, can be set to turn off |
